PDF Styling

Here’s where you’ll configure your PDF styling, setting up global configurations such as:

• Font family
• PDF width
• PDF Layout (Portrait or Landscape)
• Gap: The space between components
• Vertical Margin: Separate settings for the first page and subsequent pages
• Custom header on all pages
• Custom footer on all pages

​

Space convention

At pdf noodle, we standardize all spacing properties so you don’t have to think twice. Our spacing convention is as follows:

• No space - 0 px
• Small space - 12px
• Medium space - 20px
• Large space - 40px

​

Vertical Margin convention

We differentiate between the vertical margin for the first page and for all other pages. Typically, the first page may feature a header, meaning you might prefer no vertical margin there, while additional pages can benefit from some spacing for page breaks. Also, note that we only manage vertical margins. Horizontal margins should be adjusted directly within the individual components in your template.

---

​

Custom Footer

You can choose to insert a custom footer at the bottom of every PDF page generated. The footer is highly customizable:

• Add plain text or dynamic variables ({{variable}}).
• Insert HTML strings and inline styles for richer formatting.
• Use predefined classes to quickly render dynamic info:
  • .pageNumber → shows the current page number
  • .totalPages → shows the total number of pages
  • .date → shows the current date
  • .title → shows the template title

Additionally, you can configure the Footer Height. This value reserves vertical space at the bottom of each page to prevent the footer content from overlapping your PDF body. Set it according to the expected height of your footer design. The result will be like this:

​

Custom Header

Similarly, you can add a custom header at the top of every PDF page. The header supports the same options as the footer:

• Add static or dynamic text with variables ({{variable}}).
• Insert HTML strings and styles for full design flexibility.
• Use the predefined classes for auto-filled elements:
  • .pageNumber
  • .totalPages
  • .date
  • .title

The Header Height setting reserves vertical space at the top of the page so your header doesn’t overlap with the document content. Adjust it based on the size of your header elements.
